DGZX DVP 0.3MP ESP32 VGA 60fps ISP YUV BF3005 camera module
Product Typ：DGZX-AS-AD508A03D7-50
Active pixels：0.3MP 640X480
Sensor：BF3005(1/4")CMOS
Angle/EFL：62°/3.93mm (Optional lenses)
Frame rate：480P:60fps
Outputformats：YCbCr4:2:2、RGB565、Raw Bayer (652*480)、CCIR656(720X576)
Interface：DVP
Application：QR code scanning, Scanning translator pen; Monitor
Size：L*W*H: 50*12.5*6.4mm(Customisable)
DGZX DVP 0.3MP global shutter SC031GS VGA high-speed 180 frame black and white camera module
DGZX DVP 0.3MP VGA 480P OV7670 with ISP YUV camera module
Product Typ：DGZX-HDF7670-A30
Active pixels：0.3MP 640x480
Sensor：OV7670/0V7171(1/6”)CMOS
Angle/EFL：65°/3.76mm( Lens optional)
System：Windows、Android、Linux
Format：YUV/CbCr4:2:2 RGB565/555GRB 4:2:2Raw RGB Data
Frame rate：VGA:30fps
Application：● Scan code ● Security systems ● Smart home ● Robot
Interface：DVP
Size：L*W*H:30*12.5*4mm(customizable)
DGZX Dvp 1MP SP1405 Sensor 720P Miniature Camera Module
Product Typ：DGZX-AS-AH508A41D-9x9
Active pixels：0.9MP，1280x720
Sensor：SP1405(1/4")CMOS
Angle/EFL：Optional lens
Format：RAW
Frame rate：720p: 30 fpsVGA: 45 fps
Features & Applications：● Full-frame, sub-sampled, cropped images in variousformats and parameters are programmable througha standard l2C interface. ● SecuritySurveillance、Motion camera、lP cameraTraffic Sign Recognition 、 Video Surveillance
Interface：DVP
Size：L*W:9*9mm (Customizable)
DGZX DVP 2MP CMOS ISP Sensor Infrared Ov2643 Camera Module
Product Typ：DGZX-AS-AA348A62D1-24
Active pixels：2MP(1624x1212)
Sensor：OV2643(1/4")CMOS
View angle/EFL：Lens optional
Output format：RAW RGB,RGB565/555,YUV422,YCbCr422 and GBR422
Frame rate：UXGA(1600x1200): 15 fps 720p(1280x720): 30 fps SVGA (800x600): 30 fps
Features & application：Tablet/laptop built-in camera, drone, security gate,security monitoring, face recognition, code scanning; etc.
Interface：DVP
Size：L:24mm(8X8mm module head)
DGZX DVP 2MP HD Infrared Night Vision Camera Module
Product Typ：DGZX-HDF2643-A35
Active pixels：2MP(1624x1212)
Sensor：OV2643(1/4")CMOS
Viewangle/EFL：70°/2.8mm( Lens optional )
Output format：RAW RGB, RGB565/555, YUV422,YCbCr422 and GBR422
Frame rate：UXGA (1600x1200):15 fps 720p(1280x720): 30 fps SVGA (800x600):30 fps
Features & application：Tablet/laptop built-in camera; drone, security gate;security monitoring, face recognition, code scanning, etc.、
Interface：DVP
Size：L:35mm(8*8mm module header)
DGZX DVP 2MP HDR 1080P 30FPS wide-angle PS5268 camera module
Product Nob.：DGZX-AS-BI868A25D4-45
Active pixels：2MP 1928(H)x1088(V)
Sensor：PS5268(1/2.7")CMOS
Angle/EFL：Lens optional
Format：RAW RGB
Frame rate：1080P: 60 fps 1080P: HDR 30fps
Features：Surveillance HD-CCTV Camera、Surveillance lP CameraCar Video Recorder、Video Door Phone、Face recognitionSmart home、Self-service terminal、 lris recognition
Interface：DVP
Size：L:45mm
DGZX DVP HD 0.3MP Vga 30fps Camera Module
DGZX GC02M1 2MP MIPI HD camera module supports ISP YUV output
DGZX GC032A DVP 0.3MP ESP32 VGA 30 fps SPI Visual Headset Camera Module
DGZX-AS-BBA28A30D10-50
Active pixels：0.3MP 640x480 Sensor：GC032A(1/10”)CMOS
Format：YCbCr4:2:2、RGB565、Raw Bayer
Description：Visual Earphone Camera Module
Interface：DVP Pixel：30W Size：50*5*3mm(Customized)
Resolution：640x480 Frame Rate：30FPS
System compatible：Windows Android Linux
Sensor Type：COMS Lens：Optical
Output Format：YCbCr4:2:2/RGB565/Raw Bayer
