Dvp Camera Module
DGZX DVP 0.3MP 60fps Night Vision IR Camera Module
Product Typ：DGZX-AS-AD508A03D14-33x22
Active pixels：0.3MP 640X480
Sensor：BF3005(1/4")CMOS
Angle/EFL：Lens optional
Frame rate：VGA:60fps
Outputformats：YCbCr4:2:2、RGB565、Raw Bayer (652*480)、CCIR656(720X576)、YUV(640X480)
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L*W: 33*22mm
DGZX DVP 0.3MP HD Global Shutter 180FPS Camera Module
Product typ：DGZX-AS-BGSG8AH530D11-33
Active pixels：0.3MP 640Hx480V
Sensor：SC035HGS(1/6")CMOS
Angle：Customizable
Format：RAW MONO/RAW RGB
Frame rate：VGA: 180 fps
Features：● Bar code scanner ● Gesture Recognition ● 3D scanning ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Biometrics ● Machine vision
Interface：DVP(customizable MIPI、LVDS)
Size：L:33mm(customizable)
DGZX Dvp VGA 0.3MP with ISP Camera Module
Product Typ：DGZX-AS-BE308AA3D1-8x8
Active pixels：0.3MP 640X480
Sensor：BF3A03(1/6.5")CMOS
Angle/EFL：Customizable
Frame rate：VGA: 30fps(24MHz)/60fps(48MHz)
Formats：Bayer RGB, RGB444,RGB555, RGB565,YCBCR 4:2:2
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L*W: 8x8mm
DGZX 5MP DVP/MIPI HD Auto Focus Camera Module
Product Nob.：DGZX-HDF0500-AF
Active pixels：5MP 2608 (H)X 1960 (V)
Sensor：ZY0500(1/4")CMOS
Angle：Customizable
Format：RAW、Y/C、RGB、JPEG
Frame rate：5MP:15fps 1080p:30fps 720P:60 fps
Features：● Cellularphones ● Toys ● PCmultimedia ● Smart home ● Digital still cameras ● Driving recorder ● Action camera
Interface：DVP/MIPI
Size：Customizable
DGZX DVP 0.3MP VGA 240fps Global Exposure Camera Module
Product Typ：DGZX-AS-BOK08A30D2-24
Active pixels：0.3MP 644(H)x484(V)
Sensor：PSD030K(1/7.5")CMOS
Angle/EFL：Customizable
Frame rate：240fps
Interface：8-bit DVP
Features &Application：Machine vision; Barcode scanning; Automotive electronics; Security monitoring system; High-speed photography system
Size：L:24mm
DGZX DVP 0.3MP HD Wide Angle Camera Module
DGZX DVP 5MP 1080P IR-CUT Camera Module
Product Typ：DGZX-AS-AA048A65D82-30x30
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle：105°(Optional lens )
Frame rate：2592x1944:15fps 1080p:30fps 1280x960:45 fps 720p:60fps VGA:90fps QVGA:120 fps
Features & Application：AI intelligent recognition electronic scale, Smart home; UVA;Digital still cameras; Driving recorder; Action camera. etc
Interface：DVP
Size：L*W:30*30mm(PCB)
DGZX DVP 0.3MP VGA Low Illumination Camera Module
Product typ：DGZX-HDF25-A50
Active pixels：0.3MP 640Vx480H
Sensor：OV7725(1/4")CMOS
Angle：60°/2.8mm(lens optional)
Format：RGB/RAW
Frame rate：VGA:640*480/60FPS
Features & application：QR code scanning; fingerprint recognition, face recognition;finger vein recognition; robots,sweepers, iris recognition, etc.
Interface：DVP
Size：L*W*H:50*8*6.3mm(customizable )
