DGZX OS08A10 ULTRA HD 8MP 4K 2K Starlight Night Vision HDR Wide Dynamic Backlight Mipi Camera Module
DGZX 4MP Mipi 1/3 Inch Cmos GC4653 2K 1080P WDR Anti-Glare Camera Module
Product Typ：DGZX-AS-DB358A64M2-33
Active pixels：4MP 2560Hx1440V
Sensor：GC4653(1/3")CMOS
Angle/EFL：Optional lenses
Format：RAW
Frame rate：2560Hx 1440V: 30 fps
Features：-Surveillance; Scan Code ;Smart Home/Internet of Things -Face Recognition ; IndustrialInspection ; Hi-Res Camera
Interface：MIPI
Size：L:33mm(Customizable)
DGZX 5MP CMOS IMX335 HD USB Camera Module
Product Typ：DGZX-QQSJ-8975
Active pixels：5MP 2592(H)x1944(V)
Sensor：IMX335(1/2.8")CMOS
EFL/View Angel：Lens optional
Format：YUV422;MJPG
Frame rate：2592(H)x1944(V):30 fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：USB2.0 Drive-free Plug and Play
Size：L*W:38*38mm(Customisable)
DGZX 5MP MIPI 2K 60fps SC530AI HDR Auto-focus Camera Module
ProductTyp：DGZX-AS-AGIA8A035M1-29.6x20
Active pixels：5MP 2884Hx1624V
Sensor：SC530AI(1/2.7")CMOS
EFL/View Angel：Optional lenses
Format：RAW RGB
Frame rate：2880Hx1620V@60fps 10bit
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：MIPI
Size：L*W:29.6x20mm(Customizable)
DGZX 5MP wide-angle OV5645 2K MIPI to DVP camera module
Product Typ：DGZX-AS-AB548A65M13-50(MIPIto DVP)
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle/EFL：Lens optional
Format：RAW RGB,RGB565/555/444、YUV422/420、YCbCr422
Frame rate：QSXGA(2592x1944):15 fps 1280x960:45 fps 1080p: 30 fps 720p: 60 fps
Features：● Face recognition ● License Plate Recognition ● Monitor ● QR code barcode scanning ● Action camera ● Drone
Interface：DVP
Size：Customisable
DGZX 5MP wide-angle OV5645 2K MIPI to DVP camera module
Product Typ：DGZX-AS-AB548A65M13-50(MIPIto DVP)
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle/EFL：Lens optional
Format：RAW RGB，RGB565/555/444、YUV422/420、YCbCr422
Frame rate：QSXGA(2592x1944): 15 fps 1280x960: 45 fps 1080p: 30 fps 720p: 60 fps
Features：● Face recognition ● License Plate Recognition ● Monitor ● OR code barcode scanning ● Action camera ● Drone
Interface：DVP
Size：Customisable
DGZX GC5035 HD 5MP 2K 1080P MIPI distortion free camera module
DGZX Mipi 5MP 2K wide-angle OV5647 30FPS camera module
Product Typ：DGZX-AS-CA748A65M1-42
Active pixels：5MP 2592x1944
Sensor：OV5647(1/4")CMOS
Angle：Lens options
Format：8-/10 - bit raw RGB data.
Frame rate：2592x1944:15fps;
Application：ID & Document HD Scanning Recognition; Smart home;Drones; Action cameras; Surveillance equipment;
Interface：MIPI
Size：L:42mm(Customisable)
DGZX OS04C10 4MP 2K 1080P HD high frame rate 240fps with IR cut-off camera module
Product Typ：DGZX-AS-DA018AC40M8-46
Active pixels：4MP 2688x1520
Sensor：OS04C10(1/3")CMOS
Angle：Optional lens
Format：RAW RGB
Frame rate：2688x1520:60fps 1920x1080:80fps 1280x720:240fps
Features：● Barcode scanner ● Gesture Recognition ● 3D scanning ● Positional tracking ● lris scanning ● AR/VR ● Internet of Things ● Biometrics ● Machine vision
Interface：MIPI
Size：L:46mm(customizable)
