DGZX IMX258 13MP 4K 1080P Ultra HD AF HDR Wide Dynamic MIPI Camera Module
DGZX OS08A10 ULTRA HD 8MP 4K 2K Starlight Night Vision HDR Wide Dynamic Backlight Mipi Camera Module
DGZX 12MP 4K HD USB Camera Module
Product Typ：DGZX-QQSJ-9031
Active pixels：12MP 4032*3024
Sensor：SonyIMX377(1/2.3")CMOS
EFL/View Angel：D:110°H:88°V:66°/2.97mm (Lens optional)
Format：YUY2 ;MJPG
Frame rate：4032*3024/15FPS
Features & Application：High definition facial photography, Smart home, VideophoneSecurity monitoring; High-speed scanner; Industrial testing
Interface：USB 2.0
Size：L*W:64x25mm
DGZX 12MP MIPI HDR Nighet Vision Camera Module
Product Typ：DGZX-AS-BC778A3M3-70
Active pixels：12MP4056*3046
Sensor：SonyIMX377 (1/2.3")
EFL/View Angel：CMOS86/4.35mm(customizable)
F.NO/Distortion：3.0/<-1.2%(customizable)
Format：YUV2;MJPG
Frame rate：4K:30fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：MIPI
Size：L*W*H:70*17*23.56mm(customizable)
DGZX 12MP USB HD 4K Camera Module
Product Typ：DGZX-QQSJ-8896
Active pixels：12MP 4056*3046
Sensor：Sony IMX377 CQT (1/2.3") CMOS
EFL/View Angel：Customizable
F.NO/Distortion：Customizable
Format：YUV2;MJPG
Frame rate：4K:30fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：USB 2.0
Size：PCB/L*W:56*43mm(customizable)
DGZX 21MP MIPI Ultra HD 4K Camera Module
Product Nob.：DGZX-AS-AC038A2M1-50
Active pixels：21Mega-Pixel
Sensor：SonyIMX230(1/2.4)CMOS
Angle：Customizable
Format：YUV/JPEG/YUY2 /MJPEG
Frame rate：5360*4032 @24fps 4K2K @30fps 1080P @60fps
Features：Cellular phones、 Tablet devices、 Digital camera、Action camera、Drone
Interface：MIPI(Customizable)
Size：L:50mm(Customizable)
DGZX 8MP AF/FF 4K CMOS USB2.0 Camera Module
Product Typ：DGZX-QQSJ-8939
Active pixels：8MP(3280x2464)
Sensor：IMX179(1/3.2")CMOS
View angle/EFL：110°/2.3mm (Lens optional)
Format：YUV422;MJPG
Frame rate：8MP 15fps
Features & Application：Laptop, advertising all-in-one, high-speed scanner,UAVface recognition, mobile payment,smart home, monitoring
Interface：USB2.0 ,Drive-free plug and play
Size：L*W : 62*18mm
DGZX 8MP Auto Focus 4K USB Camera module
Product Nob.：DGZX-QQSJ-8922
Active pixels：8.46 MP
Sensor：SonyIMX415 (1/2.8") CMOS
Focal length：3.4mm (customizable)
Format：YUV422;MJPG
Frame rate：4K:30fps
Features：● Face recognition ● Mobile payment ● Smart home ● Supervising equipment ● Drone ● Action camera
Interface：USB 2.0 (Drive-free, plug and play)
Size：L*W*H:38*38*13mm(customizable)
DGZX 8MP MIPI HD 4K 60fps HDR Camera Module
Product Typ：DGZX-AS-BC878A6M4-45x24
Active pixels：8MP 3840Vx2160H
Sensor：IMX678 (1/1.8") CMOS
Angle/EFL：Lenses available on request
Format：RAW
Frame rate：4K (3840*2160):60fps
Features & Applications：Sony low light; High dynamic-backlight compensation.Live video/video conferencing, security monitoring, drone,car recorder, smart helmet,sports camera,robot,etc.
Interface：MIPI
Size：L*W:45*24mm
DGZX MIPI 12.3MP 60fps 1080P 2K Camera Module
Product Typ：DGZX-AS-CC778A5M9-65
Active pixels：12.3MP 4056(H)x3040(V)
Sensor：IMX577(1/2.3")CMOS
EFL/View Angel：Lens optional
Format：RAW12/10/8、COMP8
Frame rate：4056(H)x3040(V)@60 fps;4K2K@60fps; 1080p@240fps
Features：● Smart healthcare ● Laser engraving ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：MIPI
Size：L:65mm
DGZX MIPI 13MP 4K HD 30fps Camera Module
Product Typ：DGZX-AS-AA558A831M4-90
Active pixels：13MP 4224(H)x3136 (V)
Sensor：OV13855(1/3.06")CMOS
Angle/EFL：74.9°/3.69mm(Lens optional )
Frame rate：13MP(4224 x3136): 30 fps 3MP (2112x1568):60 fps 10MP(4224x2376):30 fps
Features &Application：Tablet/Laptop Camera;Smart Home; Sports DV/DroneVideo Conferencing; Internet of Things; Surveillance
Interface：MIPI
Size：L*W*H:90*10.2*5.6mm(8.5*8.5mm module head)
DGZX Mipi 13MP 4K HDR Camera Module
Product Typ：DGZX-AS-CC858A2M14-17.8
Active pixels：13MP 4224(H)x 3144(V)
Sensor：IMX258(1/3.06")CMOS
Angle：Optional lens
Format：RAW
Frame rate：13MP:30fps4K2K:30FPS 1080P:60fps
Applications：Face recognition; smart watch; Intelligent helmet;advertising all-in-one; high-speed scanner; Dore .etc
Interface：MIPI
Size：L:17.8mm(customizable)
