DGZX IMX258 13MP 4K 1080P Ultra HD AF HDR Wide Dynamic MIPI Camera Module
DGZX OS08A10 ULTRA HD 8MP 4K 2K Starlight Night Vision HDR Wide Dynamic Backlight Mipi Camera Module
DGZX 0.3MP MIPI HD 30fps YUV Camera Module
Product Typ：DGZX-AS-AGT08A1030M3-50
Active pixels：0.3MP 640X480
Sensor：SC030l0T(1/6.5")CMOS
Angle/EFL：Lens optional
Frame rate：640Hx480V@30fps 10bit
Outputfommats：RAW RGB/YUV422
Applications：Code scanning, Smart home, Security monitoring; loT CamIndustrialendoscope detector; Underwater detector.etc
Interface：MIPI
Size：L: 50mm (24pin Fpc)
DGZX 1.3MP MIPI HD Automotive Camera Module
Product Typ：DGZX-AS-CGTA8A021M1-24
Active pixels：1.3MP 1288Hx968V
Sensor：SC120AT(1/3.7")CMOS AEC-Q100 Grade 2 compliant
EFL/View Angel：Lens optional
Format：YUV422 / RAW
Frame rate：30fps@ 3-exposure HDR
Features & Applications：Built-in ISP; High light sensitivity ; 120dB Wide DynamicVehicle RearView lmaging; Vehicle Blind Spot DetectionVehicle 360-degree surround view and other applications
Interface：MIPI
Size：L:24mm(26pin FPC)
DGZX 1MP MIPI 720P 60FPS H63 CMOS HD Wide Dynamic Camera Module
DGZX-AS-AL368AHM7-110
Active pixels：1MP 1288Hx728V
Sensor：JX-H63(1/4")CMOS
Angle：Lens optional
Format：10-bit RGB Raw Data
Frame rate：1280x720:60fps HDR 1280x720: 30fps
Features：● Internet ofThings (loT) ● Video conferencing ● Security ● Action camera ● Drone ● Advertising machine
Interface：MIPI(DVP optional)
Size：L:110mm(customizable)
DGZX 1MP MIPI HD AR0144 Global Shutter 720P 66fps Camera Module
Product typ：DGZX-AS-BE448A10M1-15x22
Active pixels：1MP 1280Hx800V
Sensor：AR0144(1/4")CMOS
Angle：100°/2.1mm(Optional lens)
Format：RAW
Frame rate：1280Hx800V:60fps 720p:66 fps
Features：● Bar code scanner ● Gesture Recognition ● 3D scanning ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Biometrics ● Machine vision
Interface：MIPI
Size：L*W:22*15mm(Customizable)
DGZX 1MP MIPI HD Global Shutter Camera Module
Product typ：DGZX-AS-AE448A10M10-35
Active pixels：1MP 1280Hx800V
Sensor：AR0144(1/4")CMOS
Angle：Optional lens
Format：RAW
Frame rate：1280Hx800V:60fps 720p:66 fps
Features：● Gesture Recognition ● 3Dscanning ● Bar code scanner ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Machine vision ● Biometrics
Interface：MIPI
Size：L:35mm(FPC)
DGZX 2.3MP MIPI HD 120FPS Global Shutter Camera Module
Product Nob.：DGZX-AS-BE438A20M8-81
Active pixels：2.3 Mp 1920(H)x1200 (V)
Sensor：AR0234(1/2.6")CMOS
View Angle：Lens optional, please consult customer service for details
Format：RAW
Frame rate：1920(H)*1200(V):120fps 1080P:120fps 720P:120fps
Features：● Bar code scanner ● Gesture Recognition ● 3D scanning ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Biometrics ● Machine vision
Interface：MIPI
Size：L:8lmm(32pin FPC) FPC length can be customised
DGZX 2MP Mipi 1080p HD 60fps Camera Module
Product Typ：DGZX-AS-AA048A72M1-60
Active pixels：2MP 1920x1080
Sensor：0V2736(1/4")color CMOS 1080p
EFL/View Angel：Wide angle lens optional
Format：10/12-bit RAW RGB-Ir
Frame rate：1920x1080:60 fps 1280x720:90 fps
Features：Industrial&medical equipment; Scanning code, Smart homeFace recognition; Security monitoring; Motion camera;
Interface：MIPI
Size：L:60mm
DGZX 2MP MIPI 1080P HD IR-CUT Camera Module
Product Nob.：DGZX-AS-AA538A72M15-50
Active pixels：2MP 1920*1080
Sensor：OV2735(1/2.7")CMOS
Angle/EFL：Lens optional
Format：RAW
Frame rate：1080p @ 30 fps 720p @ 60 fps
Features：● Face recognition ● Advertising all-in-one machine ● PC multimedia ● Smart home/recognition ● Digital camera ● Sports camera ● Security monitoring ● Driving recorder
Interface：MIPI
Size：L:50mm(FPC)
