DGZX 0.3MP Wide Angle Low-light Night Vision USB Camera Module
DGZX 2MP 1080P Night Vision USB2.0 Camera Module
DGZX 2MP OV2735 1/3-Inch HD 1080p Low-Light IR-CUT UVC USB Camera Module
Product Typ：DGZX-QQSJ-8994
Active pixels：2MP 1920*1080
Sensor：OV2735(1/2.7")CMOS
Angle/EFL：Optional lens
Format：YUV /MJPEG
Frame rate：1080p @ 30 fps
Features：● Face recognition ● Advertising all-in-one machine ● Self-service terminals ● Smart home/Smart recognition ● Sports camera ● Security monitoring ● Driving recorder
Interface：USB2.0 Drive-free Plugand Play
Size：Customisable
DGZX 4MP MIPI HDR NIR Night Vision Camera Module
Product Nob.：DGZX-AS-BA018AA40M3-51
Active pixels：4MP 2688x1520
Sensor：OS04A10(1/1.79")CMOS
Angle/EFL：112°/3.5mm(customizable)
F.NO：2.8±0.5%(customizable)
Distortion：<-0.1%
Format：YUY2 /YUV/ JPEG /MJPEG
Frame rate：30x3 fps @ 1520p
Features：● Security camera ● VR/AR ● ADAS ● Machine vision ● Action camera ● High resolution consumer camera
Interface：MIPI
Size：L*W*H:51*24*24.6mm(customizable)
DGZX 4MP MIPI NIR Night Vision HDR Camera Module
Product Nob.：DGZX-AS-BA018AA40M3-51
Active pixels：4MP 2688x1520
Sensor：OS04A10 (1/1.79") CMOS
Angle/EFL：112/3.5mm (customizable)
F.NO：2.8士0.5% (customizable)
Distortion：<-0.1%
Format：YUY2/YUV/JPEG/MJPEG
Frame rate：30x3 fps @ 1520p
Features：● Security camera ● VR/AR ● ADAS ● Machine vision ● Action camera ● High resolution consumer camera
Interface：MIPI
Size：L*W*H:51*24*24.6mm (customizable)
DGZX 5MP MIPI HD Infrared Night Vision Camera Module
Product Typ：DGZX-AS-AA048A65M89-63x18
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle：Lens can be optional on demand
Frame rate：2592x1944:15fps 1080p:30fps1280x960:45 fps720p:60fps VGA:90fps QVGA:120 fps
Features & Application：Al intelligent recognition electronic scale, Smart home; UVA;Digital still cameras; Driving recorder, Action camera.etc
Interface：MIPI
Size：L*W:63*18mm (PCB)
DGZX 5MP Mipi Infrared night vision 2K Camera Module
Product Typ：DGZX-AS-BC538A3M27-36x22
Active pixels：5MP 2592(H)x1944(V)
Sensor：IMX335(1/2.8")CMOS
EFL/View Angel：Lens optional
Formatp：RAW
Frame rate：2592(H)x1944(V):60 fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：MIPI
Size：L*W: 36*22mm
DGZX DVP 0.3MP 60fps Night Vision IR Camera Module
Product Typ：DGZX-AS-AD508A03D14-33x22
Active pixels：0.3MP 640X480
Sensor：BF3005(1/4")CMOS
Angle/EFL：Lens optional
Frame rate：VGA:60fps
Outputformats：YCbCr4:2:2、RGB565、Raw Bayer (652*480)、CCIR656(720X576)、YUV(640X480)
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L*W: 33*22mm
DGZX HD 2MP 1080P 30fps HDR Starlight Night Vision NIR USB Camera Module
Product Typ：DGZX-QQSJ-9036
Active pixels：2MP 1920(H)*1080(V)
Sensor：SC2210(1/8")CMOS
EFL/View Angel：customizable
Video output：H.264 MJPG YUY2
Frame rate：1080P@30fps
Applications：● Industrial Camera ● Smart City Systems ● Hunting Camera
Interface：USB2.0 free drive, plug and play
Size：L*W: 38x38mm (PCB)
DGZX HD 2MP MIPI 1080P NIR Camera Module
ProductTyp：DGZX-AS-BGIA8A002M11-28
Active pixels：2MP 1928Hx1088V
Sensor：SC200AI(1/2.8”)CMOS
Angle/EFL：Lens optional
Format：RAW RGB
Frame rate：1920Hx 1080V@60fps 10bit
Features：● Security monitoring ● Scan code ● Obstacle avoidance ● Hovering ● lndustrial equipment ● Vehicle Recorder ● Advertising Player ● Action camera ● Drone ● Robot
Interface：MIPI
Size：L:28mm(22pinFPC)
DGZX HD 5MP HDR Infrared Night Vision USB2.0 Camera Module
Product Typ：DGZX-QQSJ-8874
Active pixels：5MP 2592(H)x1944(V)
Sensor：PS5520(1/2.5")CMOS
Angle/EFL：Lens optional
Format：MJPG YUY2
Frame rate：5MP:2592x1944 HDR @ 30fps
Features & Applications：Wide Dynamic; Support infrared night vision & microphoneFace recognition, Security monitoring; smart home; robotlicense plate recognition; high-speed scanner; Drones. etc.
Interface：USB 2.0, Drive-free , plug and play
Size：L*W:38*38mm(PCB)
DGZX HD 5MP HDR MIPI 3K Camera Module
Product Typ：DGZX-AS-BC578A6M1-50
Active pixels：5MP 2592(H)*1944(V)
Sensor：SonyIMX675 (1/2.8”)Cmos
EFL/View Angel：Lens optional
Format：RAW
Frame rate：3K(2592x1944):60fps
Applications：Security monitoring; car recorder, law enforcement; UAV;hunting camera; visual intercom doorbell, Robot.etc.
Interface：MIPI
Size：L:50mm(25pin FPC)
