Customized ar0233 IMX335 IMX273 IMX385 OS04C10 OS02G10 GC2093 GC1054 AR0234 MT9D111 SP1405 Camera Module
DGZX IMX258 13MP 4K 1080P Ultra HD AF HDR Wide Dynamic MIPI Camera Module
DGZX OS08A10 ULTRA HD 8MP 4K 2K Starlight Night Vision HDR Wide Dynamic Backlight Mipi Camera Module
DGZX SC035HGS HD 0.3MP VGA 180fps B&W/Color Global Exposure DVP Camera Module
DGZX 0.3MP 60fps Wide Angle CVBS Analog Camera Module
Product Typ：DGZX-AS-BPK98A804D1-26
Active pixels：3.4MP 720X480
Sensor：PC4089K(1/3")CMOS
Angle/EFL：Customizable
Format：-CVBS(NTSC/PAL) -ITU-R.BT656/CVBS -YCbCr422/RGB565/RGB444/Bayer
Frame rate：60fps/ 60 fields/sec
Features & Applications：SecuritySurveillance; Visual doorbells ; lP CameraVisual Anchor Fishing; Car Rearview Monitor; Fish Finder
Interface：Parallel/CVBS
Size：L:26mm(24pin FPC)
DGZX 0.3MP HD DVP MINI Camera Module
Product Typ：DGZX-AS-AE308AA3D1-18
Active pixels：0.3MP 640X480
Sensor：BF3A03(1/6.5")CMOS
Angle/EFL：52°/3.76mm (Lens Optional)
Frame rate：VGA: 30fps(24MHz)/60fps(48MHz)
Formats：Bayer RGB,RGB444,RGB555,RGB565,YCBCR 4:2:2
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L:18mm(20pin FPC)
DGZX 0.3MP MIPI HD 30fps YUV Camera Module
Product Typ：DGZX-AS-AGT08A1030M3-50
Active pixels：0.3MP 640X480
Sensor：SC030l0T(1/6.5")CMOS
Angle/EFL：Lens optional
Frame rate：640Hx480V@30fps 10bit
Outputfommats：RAW RGB/YUV422
Applications：Code scanning, Smart home, Security monitoring; loT CamIndustrialendoscope detector; Underwater detector.etc
Interface：MIPI
Size：L: 50mm (24pin Fpc)
DGZX 0.3MP Wide Angle Low-light Night Vision USB Camera Module
DGZX 0.8MP DVP BF3901 1/13 with ISP YUV low light camera module
Product Typ：DGZX-AS-CD108A93D6-13
Active pixels：80,000 pixels;248x328
Sensor：BF3901(1/13")CMOS
Angle/EFL：54°/1.7mm (lens optional)
Frame rate：QVGA(240*320):30fps
Output fomats：YCbCr 4:2:2,RGB444,RGB555,RGB565, Raw Baye; YUV
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L*W*H: 13*6*3mm (customizable)
DGZX 1.3MP DVP HD 720P RAW YUV 30fps Camera Module
Product Typ：DGZX-HDF1375-22
Active pixels：1.3MP 1296x1040
Sensor：HM1375(1/4")CMOS
Angle/EFL：128°/2.33mm (Lens optional )
Format：RAW, YUV422, RGB
Frame rate：30fps SXGA RAW @ 54MHz 30fps SXGA YUV @ 108MHz30fps 720 YUV @ 78MHz
Function & Application：● Face recognition/objectrecognition ● Code scanning ● Smart home ● Video surveillance ● lndustrial equipment
Interface：DVP
Size：L*W*H: 22*12.8*12.5mm
