DGZX SC035HGS HD 0.3MP VGA 180fps B&W/Color Global Exposure DVP Camera Module
DGZX 0.3MP DVP HD Global Shutter Camera Module
Product typ：DGZX-AS-DGSG8AH530D6-16
Active pixels：0.3MP 640Hx480V
Sensor：SC035HGS(1/6")CMOS
Angle：Customizable
Format：RAW MONO/RAW RGB
Frame rate：VGA: 180 fps
Features：● Gesture Recognition ● 3D scanning ● Bar code scanner ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Biometrics ● Machine vision
Interface：DVP
Size：L: 16mm (FPC Length can be customised)
DGZX 0.3MP DVP HD VGA Binocular Camera Module
Product Typ：DGZX-AS-CB828A30D8-80
Active pixels：0.3MP 640Vx480H
Sensor：GC0328 (1/6.5")CMOS
Angle/EFL：60/3.76mm (customizable)
Format：YUY2 /MJPEG
Frame rate：YUV2:640*480/30FPS
Features：● Face recognition ● Supervising equipment ● Home supplies
Interface：DVP(Customizable USB camera module)
Size：L*W*H:80*15.4*4mm(customizable)
DGZX 0.3MP HD DVP MINI Camera Module
Product Typ：DGZX-AS-AE308AA3D1-18
Active pixels：0.3MP 640X480
Sensor：BF3A03(1/6.5")CMOS
Angle/EFL：52°/3.76mm (Lens Optional)
Frame rate：VGA: 30fps(24MHz)/60fps(48MHz)
Formats：Bayer RGB,RGB444,RGB555,RGB565,YCBCR 4:2:2
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L:18mm(20pin FPC)
DGZX 0.8MP DVP BF3901 1/13 with ISP YUV low light camera module
Product Typ：DGZX-AS-CD108A93D6-13
Active pixels：80,000 pixels;248x328
Sensor：BF3901(1/13")CMOS
Angle/EFL：54°/1.7mm (lens optional)
Frame rate：QVGA(240*320):30fps
Output fomats：YCbCr 4:2:2,RGB444,RGB555,RGB565, Raw Baye; YUV
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L*W*H: 13*6*3mm (customizable)
DGZX 1.3MP DVP HD 720P RAW YUV 30fps Camera Module
Product Typ：DGZX-HDF1375-22
Active pixels：1.3MP 1296x1040
Sensor：HM1375(1/4")CMOS
Angle/EFL：128°/2.33mm (Lens optional )
Format：RAW, YUV422, RGB
Frame rate：30fps SXGA RAW @ 54MHz 30fps SXGA YUV @ 108MHz30fps 720 YUV @ 78MHz
Function & Application：● Face recognition/objectrecognition ● Code scanning ● Smart home ● Video surveillance ● lndustrial equipment
Interface：DVP
Size：L*W*H: 22*12.8*12.5mm
DGZX 1MP HD 720P FPC DVP camera module
Product Typ：DGZX-AS-HA508A41D2-28
Active pixels：1MP，1280x720
Sensor：SP1405(1/4")CMOS
Angle/EFL：70°/3.15mm(Lens optional)
Format：RAW
Frame rate：720p: 30 fps VGA: 45 fps
Features & application：● Full-frame, sub-sampled, cropped images in variousformats and parameters are programmable througha standard l2C interface. ● SecuritySurveillance 、Motion camera、Smart homeTraffic Sign Recognition 、Video Surveillance
Interface：DVP
Size：L:28mm
DGZX 2MP DVP HD 1080P HDR Camera Module
Product Typ：DGZX-AS-CI068A25D1-24
Active pixels：2MP 1920X1080
Sensor：PS5260 (1/2.7") CMOS
EFL/View Angel：74/4.35mm (customizable)
F.NO/Distortion：2.2/<-0.1% (customizable)
Format：YUV2;MJPG
Frame rate：1080P:60 fps 1080P:HDR 30fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Automotive
Interface：12bit parallel DVP (Customizable MIPI USB module)
Size：L*W*H:23.7*13*9mm(customizable)
DGZX 5MP Dvp HD Binocular Camera Module
Product Typ：DGZX-AS-AA048A65D88-45x32
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle：Optional lens
Frame rate：2592x1944:15fps 1080p:30fps 1280x960:45 fps 720p:60fps VGA:90fps QVGA:120 fps
Features & Application：Face Recognition; Live Body Detection; Security Monitoring;Self-service Terminal, Smart Home; 3D Reconstruction, etc.
Interface：DVP
Size：L*W: 45*32mm (PCB)
DGZX 5MP DVP/MIPI HD Auto Focus Camera Module
Product Nob.：DGZX-HDF0500-AF
Active pixels：5MP 2608 (H)X 1960 (V)
Sensor：ZY0500(1/4")CMOS
Angle：Customizable
Format：RAW、Y/C、RGB、JPEG
Frame rate：5MP:15fps 1080p:30fps 720P:60 fps
Features：● Cellularphones ● Toys ● PCmultimedia ● Smart home ● Digital still cameras ● Driving recorder ● Action camera
Interface：DVP/MIPI
Size：Customizable
DGZX 5MP wide-angle OV5645 2K MIPI to DVP camera module
Product Typ：DGZX-AS-AB548A65M13-50(MIPIto DVP)
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle/EFL：Lens optional
Format：RAW RGB,RGB565/555/444、YUV422/420、YCbCr422
Frame rate：QSXGA(2592x1944):15 fps 1280x960:45 fps 1080p: 30 fps 720p: 60 fps
Features：● Face recognition ● License Plate Recognition ● Monitor ● QR code barcode scanning ● Action camera ● Drone
Interface：DVP
Size：Customisable
DGZX 5MP wide-angle OV5645 2K MIPI to DVP camera module
Product Typ：DGZX-AS-AB548A65M13-50(MIPIto DVP)
Active pixels：5MP 2592x1944
Sensor：OV5640(1/4")CMOS
View angle/EFL：Lens optional
Format：RAW RGB，RGB565/555/444、YUV422/420、YCbCr422
Frame rate：QSXGA(2592x1944): 15 fps 1280x960: 45 fps 1080p: 30 fps 720p: 60 fps
Features：● Face recognition ● License Plate Recognition ● Monitor ● OR code barcode scanning ● Action camera ● Drone
Interface：DVP
Size：Customisable
