DGZX 8MP Auto Focus 4K USB Camera module
Product Nob.：DGZX-QQSJ-8922
Active pixels：8.46 MP
Sensor：SonyIMX415 (1/2.8") CMOS
Focal length：3.4mm (customizable)
Format：YUV422;MJPG
Frame rate：4K:30fps
Features：● Face recognition ● Mobile payment ● Smart home ● Supervising equipment ● Drone ● Action camera
Interface：USB 2.0 (Drive-free, plug and play)
Size：L*W*H:38*38*13mm(customizable)
DGZX 13MP USB HDR 4K Camera Module
Product Nob.：DGZX-QQSJ-8920
Active pixels：13 Mega-pixel
Sensor：SonyIMX258 (1/3.06")CMOS
Angle：75 (customizable)
Format：YUV422、MJPG
Frame rate：4260*3987:30FPS 4K2K:30FPS 1080P:60FPS
Features：● Cellular phone ● Tablet pc ● Action camera ● Drone
Interface：USB 2.0, Drive-free, plug and play
Size：L*W*H:38*38*24mm(customizable)
DGZX USB2.0 1.3MP 720P Global Shutter Camera Module
Model Number：DGZX-QQSJ-8904
Video Compression Format：H.265, H.264, MJPEG MJPG YUV YUY2 YUV422
Image Sensor：SC132GS 1/4" CMOS
Color space / compression：YUY2 / MJPG
System compatible：Linux, Windows , MAC, Android
Certification：RoHS
Interface：USB 2.0 High Speed
Module Dimensions：38mm*38mm
HD：720P
Key Feature1：Global Shutter
Key Feature2：NIR+
Pixel：1MP
DGZX 1MP USB HD 720P Camera Module
DGZX 2MP 1080P 30fps HD USB Camera Module
DGZX 2MP HD 1080P 60FPS USB Camera Module
Product Nob.：DGZX-QQSJ-8911-V1.0
Active pixels：2MP 1920x1080
View Angle/EFL：Lens can be optional on demand
Format：YUV422、MJPG、H264 Video output
Frame rate：1920*1080/60FPS(Without HDR)1920*1080/30FPS(HDR)
Features：● Face recognition ● Supervising equipment ● Smart homes
Interface：USB 2.0, Drive-free , Plug and play
Size：L*W: 38*38mm
DGZX 1MP USB HD 720P Global Shutter Camera Module
Product typ：DGZX-QQSJ-9055
Active pixels：1MP 1280Hx720V
Sensor：AR0144(1/4")CMOS
Angle：Optional lens
Format：YUY2 /MJPEG
Frame rate：720p:60 fps
Features：● Gesture Recognition ● 3D scanning ● Bar code scanner ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Biometrics ● Machine vision
Interface：USB2.0
Size：L*W:38*38mm
DGZX 2MP HD 1080P AHD/USB HDR Camera Module
Product Typ：DGZX-QQSJ-9069
Active pixels：2MP 1920(H)*1080 (V)
Sensor：(1/2.92”)CMOS
EFL/View Angel：Customizable
Video output：AHD:PAL1080P@25fps
Frame rate：USB:MJPG、YUY2
Features&Applications：Industrial monitoring; face recognition; Rear View Camera;360° Surround View Monitoring System; Smart Home.etv
Interface：AHD、USB2.0 Optional
Size：L*W:38x38mm(PCBA)
DGZX 12MP USB Ultra HD Camera Module
Product Typ：DGZX-QQSJ-9010
Active pixels：12MP 4032*3024
Sensor：SonyIMX377(1/2.3")CMOS
EFL/View Angel：D:82°H:71°V:50°/4.55mm(Lens option)
Format：YUY2 ;MJPG
Frame rate：4032*3024/15FPS
Features & Application：High definition facial photography; Smart home, VideophoneSecurity monitoring; High-speed scanner; Industrial testing
Interface：USB 2.0
Size：L*W: 38*38mm
DGZX 2MP HD 1080P USB Camera Module
Product Typ：QQSJ-9068+AS-BC708A3M38-50
Active pixels：2MP 1920(H)*1080(V)
Sensor：SonyIMX307(1/2.8")CMOS
EFL/View Angel：Customizable
Video output：YUV422;MJPG
Frame rate：1080P@30fps
Application：Face recognition; Smart payment; Smart home; Drone; RobotSecurity monitoring; Action camera; Videoconferencing, etc.
Interface：USB2.0 free drive, plug and play
Size：L*W:30x25mm(PCB)L:50mm(FPC)
DGZX 2MP HD Wide Angle USB2.0 Camera Module
Product Typ：DGZX-QQSJ-9038
Active pixels：2MP 1600*1200
Sensor：MI2010/MT9D111(1/3.2")CMOS
Angle：Customizable
Format：JPEG、YUY2、MJPG
Frame rate：1600*1200:15FPS
Features & Applications：Document &ID shooting, object detection and recognition,high-speed Scanner, detector, teaching equipment, etc.
Interface：USB 2.0,Drive-free , Plug and play
Size：L*W: 38*38mm (PCBA)
DGZX 2MP HD 1080P USB Camera Module
Product Typ：DGZX-QQSJ-9027
Active pixels：2.10MP(1920x1080)
Sensor：AR0230(1/2.7")CMOS
View angle/EFL：Lens Optional
Format：YUV422;MJPG
Frame rate：1080P:30fps
Features：● Face recognition ● Supervising equipment ● Smart home ● Video conference ● Drone ● License plate snapshot ● Action camera ● OR code barcode scanning
Interface：USB 2.0 Drive-free plug and play
Size：L*W:50*20mm(PCB)
DGZX HD 2MP 1080P 30fps HDR Starlight Night Vision NIR USB Camera Module
Product Typ：DGZX-QQSJ-9036
Active pixels：2MP 1920(H)*1080(V)
Sensor：SC2210(1/8")CMOS
EFL/View Angel：customizable
Video output：H.264 MJPG YUY2
Frame rate：1080P@30fps
Applications：● Industrial Camera ● Smart City Systems ● Hunting Camera
Interface：USB2.0 free drive, plug and play
Size：L*W: 38x38mm (PCB)
DGZX HD 5MP HDR Infrared Night Vision USB2.0 Camera Module
Product Typ：DGZX-QQSJ-8874
Active pixels：5MP 2592(H)x1944(V)
Sensor：PS5520(1/2.5")CMOS
Angle/EFL：Lens optional
Format：MJPG YUY2
Frame rate：5MP:2592x1944 HDR @ 30fps
Features & Applications：Wide Dynamic; Support infrared night vision & microphoneFace recognition, Security monitoring; smart home; robotlicense plate recognition; high-speed scanner; Drones. etc.
Interface：USB 2.0, Drive-free , plug and play
Size：L*W:38*38mm(PCB)
DGZX Ultra-HD 4K 11MP USB Camera Module
Product Typ：DGZX-QQSJ-9029
Active pixels：11MP 3840X2880
Sensor：SonyIMX377(1/2.3")CMOS
View Angel/EFL：D:42.6°H:34.5°V:26.1/10±5%mm (Lens optional)
Format：YUY2 ;MJPG
Frame rate：3840*2880:15fps 4K(3840*2160):15fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Big screen all-in-one
Interface：USB 2.0
Size：L*W: 38*38mm (PCB)
DGZX 1MP HD USB 720P 30fps Camera Module
Product Typ：DGZX-QQSJ-9049
Active pixels：1MP(1280x720)
Sensor：BF314ACS(1/4")CMOS
View angle/EFL：D:120°/2.4mm(Lens optional)
Format：MJPG, YUY
Frame rate：720P:30 fps
Features：● Face recognition ● Supervising equipment ● Smart home ● Video conference ● Drone ● License plate snapshot
Interface：USB 2.0 Drive-free plug and play
Size：L*W:38*38mm(PCB)
DGZX 2MP Dual-1080P HDR USB Camera Module
Product Typ：DGZX-QQSJ-9047
Active pixels：2MP(1920x1080)HDR+2MP(1920x1080)IR
Sensor：AR0230(1/2.7")CMOS GC2053(1/2.9")CMOS
View angle/EFL：RGB: D:76°/4.35mm IR: D:70.6°/4.35mm(Lens optional)
Format：MJPG, YUY2
Frame rate：1920 (H)*1080 (V): 30 fps
Features：● Face recognition ● Supervising equipment ● Smart home ● Live Detection ● Human evidence comparison
Interface：USB 2.0, Drive-free plug and play
Size：L*W: 80*16mm (PCB)
DGZX USB 2MP 1080P Wide Angle HDR Camera Module
Product Typ：DGZX-QQSJ-9044
Active pixels：2MP 1920x1080/2MP 1920x1080
Sensor：GC2053(1/2.9")CMOS/PS5268(1/2.7")CMOS
Angle/EFL：72°/4.43mm67/4.43mm
Format：MJPG YUY2
Frame rate：1080P: 30 fps
Features：Face recognition; live detection, security monitoring,smart home, thermal imaging thermometer, robot vision,iris recognition; license plate recognition, 3D Scanning, etc.
Interface：USB 2.0,Drive-free , plug and play
Size：L*W:45*27mm(PCB)
DGZX USB 2MP HD 1080P Camera Module
Product Typ：DGZX-QQSJ-9039+AS-AB358A02D51-84
Active pixels：2MP 1920x1080
Sensor：GC2053(1/2.9”)CMOS
View Angel/EFL：D:70.6°H:63.6°V:38°/4.35mm (Lens optional)
Format：YUY2 ; MJPG
Frame rate：1080P: 30 fps
Features：● Face recognition ● Mobile payment ● Smart home ● Drone ● Security monitoring ● Action camera ● Automotive
Interface：USB2.0
Size：PCB (L*W:50*13mm)FPC(L:84mm)
DGZX 1MP HD 720p Laptop Usb Camera Module
Product Typ：DGZX-QQSJ-9041
Active pixels：1MP 1280x720
Sensor：BF314ACS(1/4")CMOS
View angel/EFL：150°/1.7mm(Lens optional)
Output format：YUY、MJPG
Frame rate：720P :30 fps
Features：● Face recognition ● Laptops camera ● Smart home ● Drone ● Security monitoring ● Action camera ● Advertising machine
Interface：USB2.0 free drive plug&play
Size：L*W:60*8mm(PCBA)
DGZX USB 2MP 30fps HD 1080P Camera Module
Product Typ：DGZX-QQSJ-8946
Active pixels：2MP 1920*1080
Sensor：OV5645(1/4")CMOS
View angle/EFL：Customizable
Format：YUY2 /MJPEG
Frame rate：1080p: 30 fps
Features & applications：● Face recognition ● LicensePlate ● Recognition ● Monitor ● QR code barcode scanning ● Action camera ● Drone
Interface：USB 2.0 Drive-free plug and play
Size：L*W:32*32mm(PCBA)
DGZX 0.3MP Wide Angle Low-light Night Vision USB Camera Module
DGZX USB2.0 2MP 1080p Night Vision Camera Module
Product Nob.：DGZX-QQSJ-9026
Active pixels：2MP 1920*1080
Sensor：OV2735(1/2.7")CMOS
Angle/EFL：D:187.4°H:156.4°V:93.4°/2.28mm(Lens optional)
Format：MJPG/YUY/H.264
Frame rate：1080P 30fps
Features：● Face recognition ● Advertising all-in-one machine ● PC multimedia ● Smart home/recognition ● Digital camera ● Sports camera ● Security monitoring ● Driving recorder
Interface：USB 2.0 Drive free plug and play
Size：L*W: 38*38mm (PCBA)
DGZX HD 2MP USB2.0 Global Shutter Camera Module
Product Typ：DGZX-QQSJ-9013
Active pixels：2MP 1600x1200
Sensor：OG02B10(1/2.9")CMOS
View angle/EFL：D:91° H:76° V:49°/2.97mm
Format：MJPG/YUY2
Frame rate：1600x1300: 60 fps
Support system：Windows、Android、Linux
Features：● Industrial/Logistics Scanning ● Machine Vision ● Drones ● Obstacle Avoidance ● Hovering ● VRAR ● Eye tracking
Interface：USB 3.0 Drive free plug& play; Compatible with USB2.0
Size：L*W:38x38mm (PCBA)
