DGZX SC035HGS HD 0.3MP VGA 180fps B&W/Color Global Exposure DVP Camera Module
DGZX 0.3MP 60fps Wide Angle CVBS Analog Camera Module
Product Typ：DGZX-AS-BPK98A804D1-26
Active pixels：3.4MP 720X480
Sensor：PC4089K(1/3")CMOS
Angle/EFL：Customizable
Format：-CVBS(NTSC/PAL) -ITU-R.BT656/CVBS -YCbCr422/RGB565/RGB444/Bayer
Frame rate：60fps/ 60 fields/sec
Features & Applications：SecuritySurveillance; Visual doorbells ; lP CameraVisual Anchor Fishing; Car Rearview Monitor; Fish Finder
Interface：Parallel/CVBS
Size：L:26mm(24pin FPC)
DGZX 0.3MP HD DVP MINI Camera Module
Product Typ：DGZX-AS-AE308AA3D1-18
Active pixels：0.3MP 640X480
Sensor：BF3A03(1/6.5")CMOS
Angle/EFL：52°/3.76mm (Lens Optional)
Frame rate：VGA: 30fps(24MHz)/60fps(48MHz)
Formats：Bayer RGB,RGB444,RGB555,RGB565,YCBCR 4:2:2
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L:18mm(20pin FPC)
DGZX 0.3MP MIPI HD 30fps YUV Camera Module
Product Typ：DGZX-AS-AGT08A1030M3-50
Active pixels：0.3MP 640X480
Sensor：SC030l0T(1/6.5")CMOS
Angle/EFL：Lens optional
Frame rate：640Hx480V@30fps 10bit
Outputfommats：RAW RGB/YUV422
Applications：Code scanning, Smart home, Security monitoring; loT CamIndustrialendoscope detector; Underwater detector.etc
Interface：MIPI
Size：L: 50mm (24pin Fpc)
DGZX 0.3MP Wide Angle Low-light Night Vision USB Camera Module
DGZX BF20A1 MIPI VGA 0.3MP 480P 1/10″ CMOS Ultra-small structure facial recognition scanning camera module
DGZX DVP 0.3MP 60fps Night Vision IR Camera Module
Product Typ：DGZX-AS-AD508A03D14-33x22
Active pixels：0.3MP 640X480
Sensor：BF3005(1/4")CMOS
Angle/EFL：Lens optional
Frame rate：VGA:60fps
Outputformats：YCbCr4:2:2、RGB565、Raw Bayer (652*480)、CCIR656(720X576)、YUV(640X480)
Interface：DVP
Application：QR code scanning, video conferencing, vehicle monitoring
Size：L*W: 33*22mm
DGZX DVP 0.3MP ESP32 VGA 60fps ISP YUV BF3005 camera module
Product Typ：DGZX-AS-AD508A03D7-50
Active pixels：0.3MP 640X480
Sensor：BF3005(1/4")CMOS
Angle/EFL：62°/3.93mm (Optional lenses)
Frame rate：480P:60fps
Outputformats：YCbCr4:2:2、RGB565、Raw Bayer (652*480)、CCIR656(720X576)
Interface：DVP
Application：QR code scanning, Scanning translator pen; Monitor
Size：L*W*H: 50*12.5*6.4mm(Customisable)
DGZX DVP 0.3MP global shutter SC031GS VGA high-speed 180 frame black and white camera module
DGZX DVP 0.3MP HD Global Shutter 180FPS Camera Module
Product typ：DGZX-AS-BGSG8AH530D11-33
Active pixels：0.3MP 640Hx480V
Sensor：SC035HGS(1/6")CMOS
Angle：Customizable
Format：RAW MONO/RAW RGB
Frame rate：VGA: 180 fps
Features：● Bar code scanner ● Gesture Recognition ● 3D scanning ● Positional tracking ● lris scanning ● Augmented reality ● Virtual reality ● Biometrics ● Machine vision
Interface：DVP(customizable MIPI、LVDS)
Size：L:33mm(customizable)
DGZX DVP 0.3MP HD Wide Angle Camera Module
DGZX DVP 0.3MP VGA 240fps Global Exposure Camera Module
Product Typ：DGZX-AS-BOK08A30D2-24
Active pixels：0.3MP 644(H)x484(V)
Sensor：PSD030K(1/7.5")CMOS
Angle/EFL：Customizable
Frame rate：240fps
Interface：8-bit DVP
Features &Application：Machine vision; Barcode scanning; Automotive electronics; Security monitoring system; High-speed photography system
Size：L:24mm
